Din Hose Fittings Manufacturer in China

 High Quality      Large Stock and Full Category      Quick Response      Customizable      Fast Delivery

Reliable Materials: We rigorously select our raw material suppliers and accept only high quality carbon steels with high intensity and corrosive resistance performance. We select FKM or NBR O-rings and sealings with certified supply chain include ISO 9001-audited mills to ensure the sealing under high temperature or pressures. Each metal billet undergoes spectrometer testing for tensile strength (≥600MPa), yield stress(≥355), elongation(≥16) and reduction(≥40) before production.

Engineered Manufacturing: Every hydraulic fitting is precision-machined using CNC lathe machines for thread and inside bore to ensure the tolerance ±0.1 mm and validated against Parker Hannifin and Eaton's benchmarks. For hexagon or flange clamp we have machines for customized process.

Industrial Application: We guarantee our products are high quality and proven by statistics:

Salt spray test: White zinc coating(Cr3+)(8-12μm) no white rust after 120 hours and no red rust after 300 hours; Zinc-Nickle alloy coating（8-10μm）no white rust after 480 hours and no red rust after 720 hours
Temperature adaptability: Our products are fit for temperature from -40°C to 120°C
All data is recorded and accessible to clients.

Heavy-Duty Applications: Proven in extreme conditions:

Mining: anti-explosion and impact performance for Sunward mining machinery
Construction: 10,000-hour service life in LiuGong excavators
Agriculture: excellent corrosion resistance performance for Zoomlion agricultural machinery

Elite Partnership Network

We receive many customized orders every day and you could be next. Contact us today.

Each hydraulic fitting must pass 3 quality test before delivering to clients. First they need to pass the multiple tests including hardness test and pressure test.
Then they will be sent to check their tolerance.
Finally they will be sent to evaluate their outer and inner performance.
Our strict quality test procedure ensures our products with high quality and met the needs of our clients.

A hydraulic hose fitting is a connector on the end of a hose used to connect a hose to other equipment, usually to connect with another hose or with a tap or a hose appliance. It is usually made of steel, brass, stainless steel, aluminium or plastics. Hydraulic hose fittings are widely used in various industrial and living occasions, such as the transportation of gas and oil, hose replacement, pipeline systems, etc.

The hydraulic hose fittings consists of a metal pipe body, a stainless steel wire cap and a fitting. In the ship piping system, it is mainly used for the connection between the pipeline and the equipment. It can compensate for a certain relative displacement and play a role in reducing vibration and noise. However, if the selection is improper, it will not only fail to achieve the effect of vibration isolation and noise reduction, but will also cause pipeline leakage and even equipment failure due to damage to the fittings.
The selection of metal hoses mainly includes the correct selection of parameters such as diameter, connection type, working pressure, temperature correction, minimum bending radius and hose length. The diameter, connection type and working pressure directly depend on the requirements of the pipeline system, and generally there will be no problem. The temperature correction and minimum bending radius are fixed for the product and are given by the manufacturer. The problem often encounter is the selection of the length of the fittings. A fitting that is too long will cause instability, increase flow resistance, and cause additional mechanical damage and vibration problems. A fitting that is too short may not achieve the purpose of compensation, vibration reduction and noise elimination, and may also cause excessive bending stress and affect its life.

Threaded fittings: It is connected by threads between two conical or flat ports, and is commonly used for the transportation of fluids such as gas and oil.

Clamp fittings: The hose is put on the connecting pipe body through a clamp, which is suitable for occasions where the hose needs to be replaced frequently, such as the transportation pipelines in the food and pharmaceutical industries.

Flange fittings: It is connected by bolts between two flat flanges, and has the advantages of bearing large loads, bearing pressure and preventing leakage. It is widely used in chemical, petroleum and other fields.

Metal hose fittings: It includes ferrule fittings, self-fixing fittings, 90-degree fittings, Y-shaped fittings, Tee fittings, stainless steel fittings, etc., which are suitable for different installation conditions and use environments.

Each hydraulic must pass 3 quality test before delivering to clients. First the need to pass the multiple tests including hardness test and pressure test.


At Haodema, every hydraulic fitting undergoes rigorous electroplating treatment to ensure excellent corrosion resistance and long service life. We use advanced electroplating processes, including zinc plating, nickel plating and other special coating technologies, to form a dense and uniform protective layer on the surface of the product, effectively resisting the erosion of moisture, salt spray and chemicals.

Through precise current control and multi-layer plating process, we ensure that the coating has strong adhesion and high hardness, and maintains excellent protective performance even under high pressure and high wear conditions. Each batch of products undergoes multiple quality inspection processes such as salt spray testing and film thickness testing to ensure compliance with international standards. Haodema's electroplating technology not only improves the appearance and texture of the product, but also gives it stronger environmental adaptability, making our products more reliable and longer-lasting.

The excellent performance of Haodema hydraulic fittings begins with high-quality roughcast forging technology. We use high-strength alloy steel and precision forging technology to make the internal grain structure of the metal denser, greatly improving the mechanical strength and impact resistance of the product.

During the forging process, we use advanced die forging and cold heading technology to ensure that the roughcast size is accurate and free of internal defects, laying a solid foundation for subsequent machining. Each forged roughcast undergoes rigorous flaw detection and mechanical property testing to ensure that its hardness and toughness reach the industry-leading level.

Haodema's forging process not only optimizes material utilization, but also gives the product higher reliability and durability. From raw materials to finished products, we forge every detail with ingenuity, just to deliver high-quality products to our customers.
